Intel
Intel Core U7-270HX PLUS (Up to 5.3 GHz) RTX 5070Ti Chassis Only
Regular price
Sale price
£0.00
Unit price
/ per
Hide Description
|
Product Collection
|
|
|---|---|
|
Code Name
|
|
|
Vertical Segment
|
Mobile
|
|
Processor Number
|
270HX Plus
|
|
Overall Peak TOPS (Int8)
|
33
|
CPU Specifications
|
Total Cores
|
20
|
|---|---|
|
# of Performance-cores
|
8
|
|
# of Efficient-cores
|
12
|
|
# of Low Power Efficient-cores
|
0
|
|
Total Threads
|
20
|
|
Max Turbo Frequency
|
5.3 GHz
|
|
Performance-core Max Turbo Frequency
|
5.3 GHz
|
|
Efficient-core Max Turbo Frequency
|
4.7 GHz
|
|
Performance-core Base Frequency
|
2.4 GHz
|
|
Efficient-core Base Frequency
|
1.8 GHz
|
|
Cache
|
30 MB Intel® Smart Cache
|
|
Total L2 Cache
|
36 MB
|
|
Processor Base Power
|
55 W
|
|
Maximum Turbo Power
|
160 W
|
|
Minimum Assured Power
|
45 W
|
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
|
Yes
|
|
AI Software Frameworks Supported by CPU
|
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
|
|
CPU Lithography
|
TSMC N3B
|
Supplemental Information
|
Marketing Status
|
Launched
|
|---|---|
|
Launch Date
|
Q1'26
|
|
Embedded Options Available
|
No
|
|
Use Conditions
|
PC/Client/Tablet, Workstation
|
Memory Specifications
|
Max Memory Size (dependent on memory type)
|
256 GB
|
|---|---|
|
Memory Types
|
Up to DDR5 6400 MT/s
|
|
Max # of Memory Channels
|
2
|
|
ECC Memory Supported ‡
|
No
|
GPU Specifications
|
GPU Name‡
|
Intel® Graphics
|
|---|---|
|
Graphics Base Frequency
|
300 MHz
|
|
Graphics Max Dynamic Frequency
|
1.9 GHz
|
|
GPU Peak TOPS (Int8)
|
8
|
|
Graphics Output
|
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
|
|
Xe-cores
|
4
|
|
Max Resolution (HDMI)‡
|
4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)
7680 x 4320 @ 60Hz (HDMI 2.1 FRL) |
|
Max Resolution (DP)‡
|
7680 x 4320 @ 60Hz
|
|
Max Resolution (eDP - Integrated Flat Panel)‡
|
3840 x 2400 @ 120Hz
|
|
DirectX* Support
|
12
|
|
OpenGL* Support
|
4.5
|
|
OpenCL* Support
|
3
|
|
H.264 Hardware Encode/Decode
|
Yes
|
|
H.265 (HEVC) Hardware Encode/Decode
|
Yes
|
|
AV1 Encode/Decode
|
Yes
|
|
Intel® Quick Sync Video
|
Yes
|
|
# of Displays Supported ‡
|
4
|
|
Device ID
|
0x7D67
|
|
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
|
Yes
|
|
AI Software Frameworks Supported by GPU
|
OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU
|
NPU Specifications
|
NPU Name‡
|
Intel® AI Boost
|
|---|---|
|
NPU Peak TOPS (Int8)
|
13
|
|
Sparsity Support
|
Yes
|
|
Windows Studio Effects Support
|
Yes
|
|
AI Software Frameworks Supported by NPU
|
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
|
Expansion Options
|
Direct Media Interface (DMI) Revision
|
4
|
|---|---|
|
Max # of DMI Lanes
|
8
|
|
Intel® Thunderbolt™ 4
|
Yes
|
|
PCI Express Revision
|
5.0 and 4.0
|
|
PCI Express Configurations ‡
|
1x16+2x4, 2x8+2x4, 1x8+4x4
|
|
Max # of PCI Express Lanes
|
24
|
Package Specifications
|
Sockets Supported
|
FCBGA2114
|
|---|---|
|
Max Operating Temperature
|
105 °C
|
|
Package Size
|
37.5 mm x 30.2 mm
|
Advanced Technologies
|
Intel® Gaussian & Neural Accelerator
|
3.5
|
|---|---|
|
Intel® Thread Director
|
Yes
|
|
Intel® Smart Sound Technology
|
Yes
|
|
Intel® Wake on Voice
|
Yes
|
|
Intel® High Definition Audio
|
Yes
|
|
Intel® Adaptix™ Technology
|
Yes
|
|
Intel® Speed Shift Technology
|
Yes
|
|
Intel® Turbo Boost Max Technology 3.0 ‡
|
Yes
|
|
Intel® Turbo Boost Technology ‡
|
2.0
|
|
Intel® Hyper-Threading Technology ‡
|
No
|
|
Intel® 64 ‡
|
Yes
|
|
Instruction Set
|
64-bit
|
|
Instruction Set Extensions
|
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
|
Idle States
|
Yes
|
|
Enhanced Intel SpeedStep® Technology
|
Yes
|
|
Thermal Monitoring Technologies
|
Yes
|
|
Intel® Volume Management Device (VMD)
|
Yes
|
Security & Reliability
|
Intel® Threat Detection Technology (TDT)
|
Yes
|
|---|---|
|
Intel® Active Management Technology (AMT) ‡
|
No
|
|
Intel® Standard Manageability (ISM) ‡
|
Yes
|
|
Intel® Remote Platform Erase (RPE) ‡
|
No
|
|
Intel® One-Click Recovery ‡
|
No
|
|
Intel® Secure Key
|
Yes
|
|
Intel® Control-Flow Enforcement Technology
|
Yes
|
|
Intel® Total Memory Encryption - Multi Key
|
No
|
|
Intel® AES New Instructions
|
Yes
|
|
Intel® Trusted Execution Technology ‡
|
Yes
|
|
Execute Disable Bit ‡
|
Yes
|
|
Intel® OS Guard
|
Yes
|
|
Intel® Boot Guard
|
Yes
|
|
Mode-based Execute Control (MBEC)
|
Yes
|
|
Intel® Stable IT Platform Program (SIPP)
|
No
|
|
Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡
|
No
|
|
Intel® Virtualization Technology (VT-x) ‡
|
Yes
|
|
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
|
Yes
|
|
Intel® VT-x with Extended Page Tables (EPT) ‡
|
Yes
|
